GIGABYTE
B650 EAGLE AX Motherboard
MotherboardsAt a glance
Full specification ↓- Motherboard chipset family
- AMD
- CPU socket
- Socket AM5
- Supported memory types
- DDR5-SDRAM
- Max memory
- 256 GB
- Battery
- Lithium-Manganese Dioxide (LiMnO2)
- M.2 slots
- 3
£172.80inc. VAT
£144.00 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
GIGABYTE B650 EAGLE AX Motherboard, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 256 GB
Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Key features
- AMD Socket AM5：Supports AMD Ryzen 7000/ Ryzen 8000/ Ryzen 9000 Series Processors
- Unparalleled Performance：12+2+2 Phases Digital VRM Solution
- Dual Channel DDR5：4*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
- SuperSpeed Storage：1*PCIe 5.0 + 2*PCIe 4.0 M.2 Connectors
- Advanced Thermal Design & M.2 Thermal Guard：To Ensure VRM Power Stability & 25110 M.2 SSD Performance
- EZ-Latch：PCIe x16 Slot with Quick Release Design
- Fast Networks：Wi-Fi 6E 802.11ax & GbE LAN
- Extended Connectivity：DP, HDMI, Rear USB 10Gb/s
- Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Full specification
109 specifications
- Battery type
- CR2032
- Battery technology
- Lithium-Manganese Dioxide (LiMnO2)
- Battery capacity
- 220 mAh
- Number of battery cells
- 1
- Battery weight
- 3 g
- Lithium weight per battery
- 0.07 g
- Desktop Management Interface (DMI) version
- 2.7
- System Management BIOS (SMBIOS) version
- 2.7
- Clear CMOS jumper
- Yes
- ACPI version
- 5.0
- BIOS memory size
- 256 Mbit
- BIOS type
- UEFI AMI
- 3rd M.2 highest PCI Express generation
- 4.0
- 3rd M.2 largest key size
- 22110
- 2nd M.2 highest PCI Express generation
- 4.0
- 2nd M.2 largest key size
- 22110
- 1st M.2 highest PCI Express generation
- 5.0
- 1st M.2 largest key size
- 25110
- Number of M.2 (M) slots
- 3
- PCI Express x16 (Gen 3.x) slots
- 3
- PCI Express x16 (Gen 4.x) slots
- 1
- Windows operating systems supported
- Windows 10 x64, Windows 11 x64
- Power source type
- ATX
- Motherboard chipset family
- AMD
- Motherboard form factor
- ATX
- Component for
- PC
- PC health monitoring
- Fan, Temperature, Voltage, Water cooling
- Product colour
- Brown
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC897
- Motherboard chipset
- AMD B650
- Discrete graphics support
- Yes
- DirectX version
- 12.0
- HDCP
- Yes
- Maximum resolution
- 4096 x 2160 pixels
- Parallel processing technology support
- Not supported
- Number of RGB LED pin headers
- 4
- RGB LED pin header
- Yes
- TPM connector
- Yes
- Serial port headers
- 1
- 12V power connector
- Yes
- Number of water pump connectors
- 2
- EPS power connector (8-pin)
- Yes
- Number of chassis fan connectors
- 3
- Number of CPU fan connectors
- 2
- CPU fan connector
- Yes
- ATX Power connector (24-pin)
- Yes
- Front panel connector
- Yes
- Front panel audio connector
- Yes
- Number of SATA III connectors
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 1
- USB 2.0 connectors
- 3
- Maximum internal memory per slot
- 64 GB
- Unbuffered memory
- Yes
- Maximum internal memory
- 256 GB
- Supported memory clock speed (max)
- 7600 MHz
- Supported memory clock speeds
- 7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800,4400 MHz
- ECC сompatibility
- Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 4
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.3
- Bluetooth
- Yes
- WLAN controller model
- Realtek RTL8852CE
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
- Top Wi-Fi standard
- Wi-Fi 6E (802.11ax)
- Wi-Fi
- Yes
- LAN controller
- Realtek RTL8111H
- Ethernet interface type
- Gigabit Ethernet
- Ethernet LAN
- Yes
- Supported processor sockets
- Socket AM5
- Compatible processor series
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Processor socket
- Socket AM5
- Processor manufacturer
- AMD
- WiFi-AP antenna jack
- 2
- Microphone in
- Yes
- Line-in
- Yes
- Headphone outputs
- 1
- DisplayPort version
- 1.4
- DisplayPorts quantity
- 1
- HDMI version
- 2.1
- HDMI ports quantity
- 1
- PS/2 ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 1
- USB 2.0 ports quantity
- 6
- RAID levels
- 0, 1, 10
- RAID support
- Yes
- Number of HDDs supported
- 4
- Number of storage drives supported
- 7
- Supported storage drive interfaces
- M.2, SATA III
- Supported storage drive types
- HDD & SSD
- Warranty period
- 3 year(s)
- Height
- 35 mm
- Depth
- 244 mm
- Width
- 305 mm
- Country of origin
- China
- Products per shipping (inner) case
- 1 pc(s)
- Bundled software
- Norton Internet Security (OEM version) LAN bandwidth management software
- Batteries included
- Yes
- Screws included
- Yes
- Antenna included
- Yes
- Package weight
- 1.94 kg
- Package height
- 80 mm
- Package depth
- 270 mm
- Package width
- 335 mm
