GIGABYTE
B650 GAMING X AX V2 Motherboard
MotherboardsAt a glance
Full specification ↓- Motherboard chipset family
- AMD
- CPU socket
- Socket AM5
- Supported memory types
- DDR5-SDRAM
- Max memory
- 256 GB
- Battery
- Lithium-Manganese Dioxide (LiMnO2)
- M.2 slots
- 3
£149.92inc. VAT
£124.93 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
GIGABYTE B650 GAMING X AX V2 Motherboard, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 256 GB
Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Key features
- AMD Socket AM5：Supports AMD Ryzen 7000/ Ryzen 8000/ Ryzen 9000 Series Processors
- Unparalleled Performance：Direct 8+2+2 Phases Digital VRM Solution
- Dual Channel DDR5：4*SMD DIMMs with AMD EXPO & Intel® XMP Memory Module Support
- SuperSpeed Storage：1*PCIe 5.0 x4 + 2*PCIe 4.0 x4 M.2 Connectors
- Advanced Thermal Design & M.2 Thermal Guard：To Ensure VRM Power Stability & 25110 M.2 SSD Performance
- EZ-Latch：PCIe x16 Slot with Quick Release Design
- Fast Networks：2.5GbE LAN & Wi-Fi 6E 802.11ax
- Extended Connectivity：DP, HDMI, Rear USB-C 10Gb/s, Front USB-C 20Gb/s
- Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Full specification
110 specifications
- Battery type
- CR2032
- Battery technology
- Lithium-Manganese Dioxide (LiMnO2)
- Battery capacity
- 220 mAh
- Number of battery cells
- 1
- Battery weight
- 3 g
- Lithium weight per battery
- 0.07 g
- Desktop Management Interface (DMI) version
- 2.7
- System Management BIOS (SMBIOS) version
- 2.7
- Clear CMOS jumper
- Yes
- ACPI version
- 5.0
- BIOS memory size
- 256 Mbit
- BIOS type
- UEFI AMI
- 3rd M.2 highest PCI Express generation
- 4.0
- 3rd M.2 largest key size
- 25110
- 2nd M.2 highest PCI Express generation
- 4.0
- 2nd M.2 largest key size
- 25110
- 1st M.2 highest PCI Express generation
- 5.0
- 1st M.2 largest key size
- 25110
- Number of M.2 (M) slots
- 3
- PCI Express x16 (Gen 3.x) slots
- 2
- PCI Express x16 (Gen 4.x) slots
- 1
- Windows operating systems supported
- Windows 10 x64, Windows 11 x64
- Power source type
- ATX
- Motherboard chipset family
- AMD
- Motherboard form factor
- ATX
- Component for
- PC
- PC health monitoring
- Fan, Temperature, Voltage, Water cooling
- Product colour
- Brown
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC897
- Motherboard chipset
- AMD B650
- Discrete graphics support
- Yes
- DirectX version
- 12.0
- HDCP
- Yes
- Maximum resolution
- 4096 x 2160 pixels
- Parallel processing technology support
- Not supported
- Number of RGB LED pin headers
- 5
- RGB LED pin header
- Yes
- TPM connector
- Yes
- Serial port headers
- 1
- 12V power connector
- Yes
- Number of water pump connectors
- 2
- Number of EPS power connectors (8-pin)
- 1
- EPS power connector (8-pin)
- Yes
- Number of chassis fan connectors
- 3
- Number of CPU fan connectors
- 2
- CPU fan connector
- Yes
- ATX Power connector (24-pin)
- Yes
- Front panel connector
- Yes
- Front panel audio connector
- Yes
- Number of SATA III connectors
- 4
- USB 3.2 Gen 2x2 connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 1
- USB 2.0 connectors
- 2
- Maximum internal memory per slot
- 64 GB
- Unbuffered memory
- Yes
- Maximum internal memory
- 256 GB
- Supported memory clock speed (max)
- 8000 MHz
- Supported memory clock speeds
- 8000,7800,7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800,4400 MHz
- ECC сompatibility
- Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 4
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.3
- Bluetooth
- Yes
- WLAN controller model
- Realtek RTL8852CE
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
- Top Wi-Fi standard
- Wi-Fi 6E (802.11ax)
- Wi-Fi
- Yes
- LAN controller
- Realtek RTL8125
- Ethernet interface type
- 2.5 Gigabit Ethernet
- Ethernet LAN
- Yes
- Supported processor sockets
- Socket AM5
- Compatible processor series
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Processor socket
- Socket AM5
- Processor manufacturer
- AMD
- WiFi-AP antenna jack
- 2
- Microphone in
- Yes
- Line-in
- Yes
- Headphone outputs
- 1
- DisplayPort version
- 1.4
- DisplayPorts quantity
- 1
- HDMI version
- 2.1
- HDMI ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 3
- USB 2.0 ports quantity
- 3
- RAID levels
- 0, 1, 10
- RAID support
- Yes
- Number of HDDs supported
- 4
- Number of storage drives supported
- 7
- Supported storage drive interfaces
- M.2, SATA III
- Supported storage drive types
- HDD & SSD
- Warranty period
- 3 year(s)
- Height
- 35 mm
- Depth
- 244 mm
- Width
- 305 mm
- Country of origin
- China
- Products per shipping (inner) case
- 1 pc(s)
- Bundled software
- Norton Internet Security (OEM version) LAN bandwidth management software
- Batteries included
- Yes
- Screws included
- Yes
- Antenna included
- Yes
- Package weight
- 2.16 kg
- Package height
- 80 mm
- Package depth
- 270 mm
- Package width
- 335 mm
