GIGABYTE
X870E AORUS MASTER X3D ICE Motherboard
MotherboardsAt a glance
Full specification ↓- Motherboard chipset family
- AMD
- CPU socket
- Socket AM5
- Supported memory types
- DDR5-SDRAM
- Max memory
- 256 GB
- Battery
- Lithium-Manganese Dioxide (LiMnO2)
- M.2 slots
- 5
£606.24inc. VAT
£505.20 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
GIGABYTE X870E AORUS MASTER X3D ICE Motherboard, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 256 GB
Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge technology.
Key features
- X3D Turbo Mode 2.0 : Incredible X3D performance unleashed by AI
- Dual Channel DDR5: 4*DIMMs with AMD EXPO Memory Module Support. DDR5 OC up to 9000MT/s
- AMD Socket AM5: Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors
- Digital twin 18+2+2 phases VRM solution
- PCIe EZ-Latch Plus Duo: One click for screwless & quick release on dual PCIe slots
- WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
- M.2 EZ-Latch Click & Plus: Quick Release & Screwless Design on M.2 slots and heatsinks
- Ultra-Fast Storage: 5*M.2 slots, including PCIe 5.0 x4
- Fast Networking: 10GbE LAN + 5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
Full specification
117 specifications
- Battery type
- CR2032
- Battery technology
- Lithium-Manganese Dioxide (LiMnO2)
- Battery capacity
- 220 mAh
- Number of battery cells
- 1
- Battery weight
- 3 g
- Lithium weight per battery
- 0.07 g
- Desktop Management Interface (DMI) version
- 2.7
- System Management BIOS (SMBIOS) version
- 2.7
- Clear CMOS button
- Yes
- Clear CMOS jumper
- Yes
- ACPI version
- 5.0
- BIOS memory size
- 512 Mbit
- BIOS type
- UEFI AMI
- 5th M.2 highest PCI Express generation
- 4.0
- 5th M.2 largest key size
- 2280
- 4th M.2 highest PCI Express generation
- 4.0
- 4th M.2 largest key size
- 2280
- 3rd M.2 highest PCI Express generation
- 4.0
- 3rd M.2 largest key size
- 2280
- 2nd M.2 highest PCI Express generation
- 5.0
- 2nd M.2 largest key size
- 2280
- 1st M.2 highest PCI Express generation
- 5.0
- 1st M.2 largest key size
- 2580
- Number of M.2 (M) slots
- 5
- PCI Express x16 (Gen 5.x) slots
- 2
- PCI Express x16 (Gen 4.x) slots
- 1
- Windows operating systems supported
- Windows 11 x64
- Cooling type
- Passive
- Power source type
- ATX
- Motherboard chipset family
- AMD
- Motherboard form factor
- ATX
- Component for
- PC
- PC health monitoring
- CPU, Fan, Temperature, Voltage, Water cooling
- Product colour
- White
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC1220-VB/ESS 9118
- Motherboard chipset
- AMD X870E
- DirectX version
- 12.0
- HDCP
- Yes
- Maximum resolution
- 4096 x 2304 pixels
- Parallel processing technology support
- Not supported
- Number of RGB LED pin headers
- 5
- RGB LED pin header
- Yes
- TPM connector
- Yes
- Number of water pump connectors
- 2
- Number of temperature sensor headers
- 2
- Number of noise detection headers
- 1
- Number of EPS power connectors (8-pin)
- 3
- EPS power connector (8-pin)
- Yes
- Chassis intrusion connector
- Yes
- Number of chassis fan connectors
- 6
- Number of CPU fan connectors
- 2
- CPU fan connector
- Yes
- ATX Power connector (24-pin)
- Yes
- Front panel connector
- Yes
- Front panel audio connector
- Yes
- Number of SATA III connectors
- 2
- USB 3.2 Gen 2x2 connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 2
- USB 2.0 connectors
- 2
- Maximum internal memory per slot
- 64 GB
- Unbuffered memory
- Yes
- Maximum internal memory
- 256 GB
- Supported memory clock speed (max)
- 9000 MHz
- Supported memory clock speeds
- 9000,8800,8600,8400,8200,8000,7800,7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800 MHz
- ECC сompatibility
- ECC & Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 4
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.4
- Bluetooth
- Yes
- WLAN controller model
- MediaTek MT7927
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- Top Wi-Fi standard
- Wi-Fi 7 (802.11be)
- Wi-Fi
- Yes
- LAN controller
- Realtek RTL8126, Realtek RTL8127
- Ethernet interface type
- 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
- Ethernet LAN
- Yes
- Weight
- 3.82 kg
- Supported processor sockets
- Socket AM5
- Compatible processor series
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Processor socket
- Socket AM5
- Processor manufacturer
- AMD
- WiFi-AP antenna jack
- 2
- Digital audio optical out
- 1
- S/PDIF out port
- Yes
- Line-in
- Yes
- Headphone outputs
- 1
- DisplayPort version
- 1.4
- HDMI version
- 2.1
- HDMI ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 2
- USB4 Gen 2x2 ports quantity
- 2
- USB 3.2 Gen 2x2 Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 7
- RAID levels
- 0, 1, 5, 10
- RAID support
- Yes
- Number of HDDs supported
- 2
- Number of storage drives supported
- 7
- Supported storage drive interfaces
- M.2, PCI Express 4.0, PCI Express 5.0, SATA III
- Supported storage drive types
- HDD & SSD
- Warranty period
- 3 year(s)
- Height
- 35 mm
- Depth
- 244 mm
- Width
- 305 mm
- Country of origin
- Taiwan
- Products per shipping (inner) case
- 1 pc(s)
- Bundled software
- Norton® Internet Security (OEM version)
- Batteries included
- Yes
- Screws included
- Yes
- Antenna included
- Yes
- Package weight
- 4.38 kg
- Package height
- 92 mm
- Package depth
- 310 mm
- Package width
- 340 mm
