iiyama
TW2223AS-B3P Signage Display Interactive flat panel
54.6 cm (21.5") Wi-Fi 450 cd/m² Full HD Black Touchscreen Built-in processor Android 24/7
Signage DisplaysAt a glance
Full specification ↓- Product design
- Interactive flat panel
- Display
- 21.5"
- Display brightness
- 450 cd/m²
- HD type
- Full HD
- Colour
- Black
- OS
- Android
£488.16inc. VAT
£406.80 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
iiyama TW2223AS-B3P, Interactive flat panel, 54.6 cm (21.5"), 1920 x 1080 pixels, Wi-Fi, 24/7
The ProLite TW2223AS-B3P interactive Touchpanel-PC is a perfect choice for high-use environments. The IPS panel, integrated in a slim and elegant bezel, delivers both excellent colour performance with wide viewing angles and noticeably sharper images. The In-cell 10tp PCAP touch technology ensures a fluid and natural touch experience. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Thanks to the pre-installed Android 14 operating system, it is possible to easily customize the monitor by installing applications directly to it. In combination with the 32GB storage, Wi-Fi connection, LAN (RJ45) and Bluetooth connectors, it makes the monitor especially suited for POS systems or information points in retail shops to educate customers about your products, as well as virtually limitless smart home applications. Thanks to Power over Ethernet (PoE), both power and data are delivered through a single cable, simplifying installation and reducing additional cables. Additionally, it integrates effortlessly with iiSignage2 , iiyama’s Content Management System (CMS), giving you full control over your messages and advertising.
Key features
- Indoor Interactive flat panel Black
- 54.6 cm (21.5") 1920 x 1080 pixels 450 cd/m²
- Touchscreen 14 ms
- Ethernet LAN Wi-Fi
- Built-in speaker(s) 4 W
Full specification
93 specifications
- RMS rated power
- 4 W
- Number of built-in speakers
- 2
- Built-in speaker(s)
- Yes
- Google applications
- Google Chrome, Gmail, Google Calendar
- Operating system version
- 14
- Operating system installed
- Android
- Internal storage capacity
- 32 GB
- Internal memory
- 4 GB
- Processor model
- Rockchip RK3576
- Processor family
- ARM Rockchip
- Built-in processor
- Yes
- Computer system
- Yes
- Bezel colour
- Black
- Panel mounting interface
- 100 x 100 mm
- VESA mounting
- Yes
- Screen shape
- Flat
- Product colour
- Black
- Orientation
- Horizontal/Vertical
- Placement supported
- Indoor
- Product design
- Interactive flat panel
- Horizontal scan range
- 31 - 83 kHz
- Colour depth
- 8 bit
- Glass thickness
- 2.9 mm
- Surface hardness
- 6H
- Display diagonal (metric)
- 54.6 cm
- Active display area (W x H)
- 476.1 x 267.8 mm
- Pixel pitch
- 0.248 x 0.248 mm
- Display number of colours
- 16.7 million colours
- Viewing angle, vertical
- 178°
- Viewing angle, horizontal
- 178°
- Contrast ratio (typical)
- 1500:1
- Response time
- 14 ms
- Native aspect ratio
- 16:9
- Number of simultaneous touchpoints
- 10
- Touchscreen technology
- Projected capacitive system
- Touchscreen
- Yes
- HD type
- Full HD
- Display brightness
- 450 cd/m²
- Display resolution
- 1920 x 1080 pixels
- Display diagonal
- 54.6 cm (21.5")
- Panel type
- IPS
- Wi-Fi standards
- Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b
- Wi-Fi
- Yes
- Ethernet LAN data rates
- 1000 Mbit/s
- Ethernet LAN
- Yes
- Viewable size, horizontal
- 47.6 cm
- Viewable size, vertical
- 26.8 cm
- Power supply type
- External
- Bluetooth version
- 5.3
- AC adapter included
- Yes
- Brightness
- 450 cd/m²
- Bluetooth
- Yes
- Compatible operating systems
- All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
- Cable management
- Yes
- Quick start guide
- Yes
- Mean time between failures (MTBF)
- 50000 h
- HDCP
- Yes
- Operating hours (hours/days)
- 24/7
- Purpose
- Universal
- Compatible memory cards
- SD
- Card reader integrated
- Yes
- Microphone in
- Yes
- Audio (L/R) in
- 2
- Ethernet LAN (RJ-45) ports
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 1
- USB connector type
- USB Type-C
- USB ports quantity
- 3
- USB port
- Yes
- DVI port
- No
- Power over Ethernet (PoE)
- Yes
- Power consumption (off)
- 0.3 W
- Power consumption (standby)
- 0.5 W
- Power consumption (typical)
- 15.4 W
- User controls
- Power switch, volume/ button +, volume/ button -
- Sustainability certificates
- ErP
- Compliance certificates
- CE, EAC, REACH, RoHS, UKCA, WEEE
- Weight (with stand)
- 3.64 kg
- Height (with stand)
- 302 mm
- Depth (with stand)
- 32 mm
- Width (with stand)
- 504.5 mm
- Weight
- 3.64 kg
- Height
- 302 mm
- Depth
- 32 mm
- Width
- 504.5 mm
- Display weight
- 3.64 kg
- Display height
- 302 mm
- Display depth
- 32 mm
- Display width
- 504.5 mm
- Cables included
- AC
- Package weight
- 6 kg
- Package height
- 126 mm
- Package depth
- 375 mm
- Package width
- 580 mm
Why choose this
Connectivity
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, which simplifies installation in areas where many cables would interfere with the environment.
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.
