MSI
B760M GAMING PLUS WIFI motherboard Intel B760 LGA 1700 micro ATX
MotherboardsAt a glance
Full specification ↓- Chipset
- Intel B760
- CPU socket
- LGA 1700
- Form factor
- micro ATX
- Supported memory types
- DDR5-SDRAM
- Max memory
- 192 GB
- M.2 slots
- 2
£177.12inc. VAT
£147.60 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
MSI B760M GAMING PLUS WIFI, Intel, LGA 1700, Intel® Celeron®, Intel® Pentium® Gold, LGA 1700, DDR5-SDRAM, 192 GB
B760M GAMING PLUS WIFI is designed with tons of connectivity, flexible tools, and convenient Wi-Fi solution with DDR5 memory version for gamers who want it all.
LIGHTNING GEN 4 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 64GB/s.
REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
LIGHTNING GEN 4 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 64GB/s.
REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
Key features
- Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
- Supports DDR5 Memory, Dual Channel DDR5 6800+MHz (OC)
- Enhanced Power Design: 12+1 Duet Rail Power System with P-PAK, 8-pin + 4-pin CPU power connectors, Core Boost, Memory Boost
- Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads are built for high performance system and non-stop gaming experience
- Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, USB 3.2 Gen 2 10G
- 2.5G LAN with Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- High Quality PCB: 6-layer PCB made by 2oz thickened copper
Full specification
60 specifications
- System Management BIOS (SMBIOS) version
- 3.5
- Clear CMOS jumper
- Yes
- ACPI version
- 6.4
- BIOS memory size
- 256 Mbit
- BIOS type
- UEFI AMI
- Number of M.2 (M) slots
- 2
- PCI Express x16 (Gen 4.x) slots
- 2
- PCI Express x1 (Gen 3.x) slots
- 2
- Windows operating systems supported
- Windows 10, Windows 11
- Power source type
- ATX
- Motherboard chipset family
- Intel
- Motherboard form factor
- micro ATX
- Component for
- PC
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC897
- Motherboard chipset
- Intel B760
- RGB LED pin header
- Yes
- TPM connector
- Yes
- CPU fan connector
- Yes
- ATX Power connector (24-pin)
- Yes
- Front panel connector
- Yes
- Front panel audio connector
- Yes
- Number of SATA III connectors
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 4
- USB 2.0 connectors
- 4
- Maximum internal memory
- 192 GB
- Supported memory clock speed (max)
- 6800 MHz
- Supported memory clock speeds
- 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5400, 5200, 5000, 4800 MHz
- ECC сompatibility
- Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 4
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.3
- Bluetooth
- Yes
- Wi-Fi standards
- 802.11a, 802.11ad, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
- Top Wi-Fi standard
- Wi-Fi 6E (802.11ax)
- Wi-Fi
- Yes
- Ethernet interface type
- 2.5 Gigabit Ethernet
- Ethernet LAN
- Yes
- Supported processor sockets
- LGA 1700
- Maximum number of SMP processors
- 1
- Compatible processor series
- Intel® Celeron®, Intel® Pentium® Gold
- Processor socket
- LGA 1700
- Processor manufacturer
- Intel
- DisplayPort version
- 1.4
- DisplayPorts quantity
- 2
- HDMI version
- 2.1
- HDMI ports quantity
- 2
- Ethernet LAN (RJ-45) ports
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- USB 2.0 ports quantity
- 2
- RAID levels
- 0, 1, 5, 10
- RAID support
- Yes
- Number of storage drives supported
- 6
- Supported storage drive interfaces
- M.2, SATA III
- Depth
- 243.8 mm
- Width
- 243.8 mm
