MSI
B760M PROJECT ZERO motherboard Intel B760 LGA 1700 micro ATX
MotherboardsAt a glance
Full specification ↓- Chipset
- Intel B760
- CPU socket
- LGA 1700
- Form factor
- micro ATX
- Max memory
- 192 GB
- Supported memory types
- DDR5-SDRAM
- M.2 slots
- 2
£275.04inc. VAT
£229.20 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
MSI B760M PROJECT ZERO, Intel, LGA 1700, Intel® Celeron®, Intel® Pentium® Gold, LGA 1700, 192 GB, DDR5-SDRAM
The B760M PROJECT ZERO features a unique back-connect design that reduces the complexity of cable management, resulting in a neater and more aesthetically pleasing appearance for the system. It’s compatible with Intel 14th/13th/12th Processors, supports DDR5, and comes equipped with a 2.5G LAN and Wi-Fi 6E solution. This makes it an excellent choice among mATX motherboards.
ABSOLUTE SIMPLICITY
B760M PROJECT ZERO moves the power connectors, fan connectors, and other pin headers to the back of the motherboard. This provides a cleaner and neater front view, allowing the motherboard, liquid cooler, and graphics card's aesthetic design to be fully displayed.
LIGHTNING GEN 5 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 128GB/s.
SMT PCIE 5.0 SLOT
The advanced SMT(Surface Mount Technology) PCIE slot diminish interference and electrical noise, fully support the PCI-E 5.0 signal.
REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
ABSOLUTE SIMPLICITY
B760M PROJECT ZERO moves the power connectors, fan connectors, and other pin headers to the back of the motherboard. This provides a cleaner and neater front view, allowing the motherboard, liquid cooler, and graphics card's aesthetic design to be fully displayed.
LIGHTNING GEN 5 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 128GB/s.
SMT PCIE 5.0 SLOT
The advanced SMT(Surface Mount Technology) PCIE slot diminish interference and electrical noise, fully support the PCI-E 5.0 signal.
REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
Key features
- Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
- Supports DDR5 Memory, up to 7800+(OC) MHz
- Enhanced Power Design: 12+1+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
Full specification
62 specifications
- System Management BIOS (SMBIOS) version
- 3.5
- Clear CMOS jumper
- Yes
- ACPI version
- 6.4
- BIOS memory size
- 256 Mbit
- BIOS type
- UEFI AMI
- Number of M.2 (M) slots
- 2
- PCI Express x16 (Gen 5.x) slots
- 1
- PCI Express x16 (Gen 4.x) slots
- 1
- PCI Express x1 (Gen 3.x) slots
- 2
- Windows operating systems supported
- Windows 10, Windows 11
- Power source type
- ATX
- Motherboard chipset family
- Intel
- Motherboard form factor
- micro ATX
- Component for
- PC
- Product colour
- Black, White
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC897
- Motherboard chipset
- Intel B760
- RGB LED pin header
- Yes
- TPM connector
- Yes
- CPU fan connector
- Yes
- ATX Power connector (24-pin)
- Yes
- Front panel connector
- Yes
- Front panel audio connector
- Yes
- Number of SATA III connectors
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 4
- USB 2.0 connectors
- 4
- Maximum internal memory
- 192 GB
- Supported memory clock speed (max)
- 7800 MHz
- Supported memory clock speeds
- 4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800 MHz
- ECC сompatibility
- Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 4
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.3
- Bluetooth
- Yes
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
- Top Wi-Fi standard
- Wi-Fi 6E (802.11ax)
- Wi-Fi
- Yes
- Ethernet interface type
- 2.5 Gigabit Ethernet
- Ethernet LAN
- Yes
- Maximum internal memory supported by processor
- 192 GB
- Supported processor sockets
- LGA 1700
- Maximum number of SMP processors
- 1
- Compatible processor series
- Intel® Celeron®, Intel® Pentium® Gold
- Processor socket
- LGA 1700
- Processor manufacturer
- Intel
- DisplayPort version
- 1.4
- DisplayPorts quantity
- 1
- HDMI version
- 2.1
- HDMI ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- USB 2.0 ports quantity
- 2
- RAID levels
- 0, 1, 5, 10
- RAID support
- Yes
- Supported storage drive interfaces
- M.2, SATA III
- Depth
- 243.8 mm
- Width
- 243.8 mm
