MSI
MAG B860 TOMAHAWK WIFI motherboard Intel B860 LGA 1851 (Socket V1) ATX
MotherboardsAt a glance
Full specification ↓- Chipset
- Intel B860
- CPU socket
- LGA 1851 (Socket V1)
- Form factor
- ATX
- Compatible processor series
- Intel Core Ultra (Series 2)
- Max memory
- 256 GB
- Supported memory types
- DDR5-SDRAM
£207.23inc. VAT
£172.69 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
MSI MAG B860 TOMAHAWK WIFI, Intel, LGA 1851 (Socket V1), Intel Core Ultra (Series 2), LGA 1851, 256 GB, DDR5-SDRAM
MAG B860 TOMAHAWK WIFI is designed for gamers with a stable, durable and DIY friendly foundation for their PC builds. Coming up with Killer Wi-Fi 7 solution and 5G LAN, Thunderbolt 4, PCIe 5.0 solutions, Supplemental PCIe Power and exclusive EZ DIY features, it's ready for the battlefied of Intel Core Ultra processors.
Key features
- Support Intel® Core™ Ultra Processors (Series 2) for LGA 1851 socket
- Supports DDR5 Memory, Dual Channel DDR5 9200+ MT/s (OC)
- Ultra Performance: 12+1+1+1 Duet Rail Power System 60A SPS, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB made by 2oz thickened copper and server-grade level material
- Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
- EZ DIY: EZ PCIe Release, EZ M.2 Shield Frozr II, EZ M.2 Clip II and EZ Antenna
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
- Ultra Connect: Thunderbolt™ 4 port, Intel® Killer™ 5G LAN & Intel® Killer™ Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
Full specification
69 specifications
- System Management BIOS (SMBIOS) version
- 3.7
- ACPI version
- 6.5
- BIOS memory size
- 256 Mbit
- BIOS type
- UEFI AMI
- 3rd M.2 highest PCI Express generation
- 4.0
- 3rd M.2 largest key size
- 2280
- 2nd M.2 highest PCI Express generation
- 4.0
- 2nd M.2 largest key size
- 22110
- 1st M.2 highest PCI Express generation
- 5.0
- 1st M.2 largest key size
- 2280
- Number of M.2 (M) slots
- 3
- PCI Express x16 (Gen 5.x) slots
- 1
- PCI Express x16 (Gen 4.x) slots
- 1
- PCI Express x1 slots
- 1
- Windows operating systems supported
- Windows 11 x64
- Motherboard chipset family
- AMD
- Motherboard form factor
- ATX
- Component for
- PC
- Product colour
- Black
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC897
- Motherboard chipset
- Intel B860
- On-board graphics card
- No
- Number of RGB LED pin headers
- 3
- RGB LED pin header
- Yes
- Number of water pump connectors
- 1
- Number of CPU fan connectors
- 1
- CPU fan connector
- Yes
- Total number of SATA connectors
- 4
- Number of SATA III connectors
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 2
- USB 2.0 connectors
- 4
- Maximum internal memory
- 256 GB
- Supported memory clock speed (max)
- 9200 MHz
- Supported memory clock speeds
- 5600,6400,7200,9200 MHz
- ECC сompatibility
- Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 4
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.4
- Bluetooth
- Yes
- WLAN controller model
- Killer Wi-Fi 7 1750x
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- Top Wi-Fi standard
- Wi-Fi 7 (802.11be)
- Wi-Fi
- Yes
- Ethernet interface type
- 5 Gigabit Ethernet
- Ethernet LAN
- Yes
- Maximum internal memory supported by processor
- 256 GB
- Supported processor sockets
- LGA 1851
- Compatible processor series
- Intel Core Ultra (Series 2)
- Processor socket
- LGA 1851 (Socket V1)
- Processor manufacturer
- Intel
- HDMI version
- 2.1
- HDMI ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- USB 3.2 Gen 2x2 Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 4
- USB 2.0 ports quantity
- 4
- RAID levels
- 0, 1, 5, 10
- RAID support
- Yes
- Number of HDDs supported
- 4
- Number of storage drives supported
- 7
- Supported storage drive interfaces
- M.2, Micro SATA III
- Supported storage drive types
- HDD & SSD
- Depth
- 304.8 mm
- Width
- 243.8 mm
