£444.96
inc. VAT
1 / 5
MSI
MPG X870I EDGE TI EVO WIFI motherboard AMD X870 Socket AM5 mini ITX
MotherboardsAt a glance
Full specification ↓- Chipset
- AMD X870
- CPU socket
- Socket AM5
- Form factor
- mini ITX
- Supported memory types
- DDR5-SDRAM
- Max memory
- 256 GB
- M.2 slots
- 1
£444.96inc. VAT
£370.80 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
MSI MPG X870I EDGE TI EVO WIFI, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 256 GB
MPG X870I EDGE TI EVO WIFI is covered with a silver-white color scheme for white PC build lovers to show off different identity. It is also powerful because of its true Wi-Fi 7 solution, 5G LAN, USB4, and the latest PCIe 5.0 compatibility, and this is the best white theme X870 ITX motherboard for AMD Ryzen™ 9000 series processors.
Key features
- Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
- Supports DDR5 Memory, Dual Channel DDR5 10000+ MT/s (OC)
- Ultra Performance: 8+2+1 Duet Rail Power System, Core Boost, Memory Boost, 12-layer PCB made by 1oz thickened copper and server-grade level material
- Frozr Guard: Enlarged heatsink, MOSFET thermal pads rated for 7W/mk and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
- EZ DIY: EZ Antenna, EZ Conn-Design and EZ Front Panel Cable
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 M.2
- Ultra Connect: USB4 and 5G LAN with Wi-Fi 7 Solution - The latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
- Audio Boost 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
Full specification
64 specifications
- System Management BIOS (SMBIOS) version
- 3.7
- ACPI version
- 6.5
- BIOS memory size
- 512 Mbit
- BIOS type
- UEFI AMI
- 1st M.2 highest PCI Express generation
- 5.0
- 1st M.2 largest key size
- 2280
- Number of M.2 (M) slots
- 1
- PCI Express x16 (Gen 5.x) slots
- 1
- PCI Express x16 (Gen 3.x) slots
- 1
- PCI Express x16 (Gen 4.x) slots
- 1
- Motherboard chipset family
- AMD
- Motherboard form factor
- mini ITX
- Component for
- PC
- PC health monitoring
- CPU, Fan, Temperature, Voltage
- Product colour
- White
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC4080
- Motherboard chipset
- AMD X870
- On-board graphics card
- No
- EPS power connector (8-pin)
- Yes
- CPU fan connector
- Yes
- ATX Power connector (24-pin)
- Yes
- Total number of SATA connectors
- 2
- Number of SATA III connectors
- 2
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 2
- USB 2.0 connectors
- 2
- Maximum internal memory
- 256 GB
- Supported memory clock speed (max)
- 9000 MHz
- Supported memory clock speeds
- 9000,8000,7000 MHz
- ECC сompatibility
- Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 2
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.4
- Bluetooth
- Yes
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- Top Wi-Fi standard
- Wi-Fi 7 (802.11be)
- Wi-Fi
- Yes
- LAN controller
- Realtek RTL8126
- Ethernet interface type
- 5 Gigabit Ethernet
- Ethernet LAN
- Yes
- Supported processor sockets
- Socket AM5
- Compatible processor series
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Processor socket
- Socket AM5
- Processor manufacturer
- AMD
- S/PDIF out port
- Yes
- Microphone in
- Yes
- DisplayPorts quantity
- 2
- HDMI version
- 2.1
- HDMI ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- USB4 Gen 2x2 ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
- RAID levels
- 0, 1, 5, 10
- RAID support
- Yes
- Number of HDDs supported
- 2
- Number of storage drives supported
- 3
- Supported storage drive interfaces
- M.2, SATA III
- Supported storage drive types
- HDD & SSD
- Depth
- 170 mm
- Width
- 170 mm
