£167.93
inc. VAT
1 / 5
MSI
PRO B860-P WIFI motherboard Intel B860 LGA 1851 (Socket V1) ATX
MotherboardsAt a glance
Full specification ↓- Chipset
- Intel B860
- CPU socket
- LGA 1851 (Socket V1)
- Form factor
- ATX
- Compatible processor series
- Intel Core Ultra (Series 2)
- Max memory
- 256 GB
- Supported memory types
- DDR5-SDRAM
£167.93inc. VAT
£139.94 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
MSI PRO B860-P WIFI, Intel, LGA 1851 (Socket V1), Intel Core Ultra (Series 2), LGA 1851, 256 GB, DDR5-SDRAM
PRO B860-P WIFI offers a simple design with a harmonious silver color scheme that perfectly matches both white and black PC builds. It is engineered with many exclusive features of MSI, a true Wi-Fi 7 with EZ Antenna, 5G LAN, Thunderbolt 4, PCIe 5.0 M.2, and Supplemental PCIe Power, ready for the Intel® Core™ Ultra processors.
Key features
- Support Intel® Core™ Ultra Processors (Series 2) for LGA 1851 socket
- Supports DDR5 Memory, Dual Channel DDR5 8800+ MT/s (OC)
- Ultra Performance: 12+1+1+1 Duet Rail Power System with P-PAK, 8+4-pin CPU power connectors, Core Boost, Memory Boost, 6-layer server-grade PCB
- Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
- EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II and EZ Antenna
- Lightning Fast Game experience: PCIe 5.0 slot and Lightning Gen 5 x4 M.2
- Ultra Connect: Thunderbolt™ 4 port, 5G LAN with Intel Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
- Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience
Full specification
65 specifications
- System Management BIOS (SMBIOS) version
- 3.7
- ACPI version
- 6.5
- BIOS memory size
- 256 Mbit
- BIOS type
- UEFI AMI
- 3rd M.2 highest PCI Express generation
- 4.0
- 3rd M.2 largest key size
- 2280
- 2nd M.2 highest PCI Express generation
- 4.0
- 2nd M.2 largest key size
- 2280
- 1st M.2 highest PCI Express generation
- 5.0
- 1st M.2 largest key size
- 2280
- Number of M.2 (M) slots
- 3
- PCI Express x16 (Gen 5.x) slots
- 1
- PCI Express x16 (Gen 4.x) slots
- 3
- Windows operating systems supported
- Windows 11 x64
- Motherboard chipset family
- AMD
- Motherboard form factor
- ATX
- Component for
- PC
- Product colour
- Black
- Audio output channels
- 7.1 channels
- Audio chip
- Realtek ALC897
- Motherboard chipset
- Intel B860
- Number of RGB LED pin headers
- 3
- RGB LED pin header
- Yes
- Number of water pump connectors
- 1
- Number of CPU fan connectors
- 1
- CPU fan connector
- Yes
- Total number of SATA connectors
- 4
- Number of SATA III connectors
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 4
- USB 2.0 connectors
- 4
- Maximum internal memory
- 256 GB
- Supported memory clock speed (max)
- 8800 MHz
- Supported memory clock speeds
- 4800,6400,8800 MHz
- ECC сompatibility
- Non-ECC
- Memory channels
- Dual-channel
- Memory slots type
- DIMM
- Number of memory slots
- 4
- Supported memory types
- DDR5-SDRAM
- Bluetooth version
- 5.4
- Bluetooth
- Yes
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- Top Wi-Fi standard
- Wi-Fi 7 (802.11be)
- Wi-Fi
- Yes
- Ethernet interface type
- 5 Gigabit Ethernet
- Ethernet LAN
- Yes
- Maximum internal memory supported by processor
- 256 GB
- Supported processor sockets
- LGA 1851
- Compatible processor series
- Intel Core Ultra (Series 2)
- Processor socket
- LGA 1851 (Socket V1)
- Processor manufacturer
- Intel
- HDMI version
- 2.1
- HDMI ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- USB 2.0 ports quantity
- 4
- RAID levels
- 0, 1, 5, 10
- RAID support
- Yes
- Number of HDDs supported
- 4
- Number of storage drives supported
- 7
- Supported storage drive interfaces
- M.2, Micro SATA III
- Supported storage drive types
- HDD & SSD
- Depth
- 304.8 mm
- Width
- 243.8 mm
