StarTech.com
Dual Monitor USB 3.0 Laptop Docking Station with HDMI/DVI/VGA
3x USB-A Hub, GbE, Audio, Universal Type-A Dock for Windows/macOS/ChromeOS - TAA Compliant
Laptop Docks & Port ReplicatorsAt a glance
Full specification ↓- Connectivity technology
- Wired
- Host interface
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Copper ethernet cabling technology
- 1000BASE-T, 100BASE-TX, 10BASE-T
- Colour
- Black
- Ethernet LAN (RJ-45) ports
- 1
£80.99inc. VAT
£67.49 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
StarTech.com Dual Monitor USB 3.0 Laptop Docking Station with HDMI/DVI/VGA, 3x USB-A Hub, GbE, Audio, Universal Type-A Dock for Windows/macOS/ChromeOS - TAA Compliant, Wired, USB 3.2 Gen 1 (3.1 Gen 1) Type-B, 10,100,1000 Mbit/s, 1000BASE-T, 100BASE-TX, 10BASE-T, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, Black
Maximize your productivity with this Dual Monitor USB-A Docking Station featuring Gigabit Ethernet, USB Hub, and Audio
This USB 3.0 dock combines three USB 3.0 ports, headphone and microphone audio connectors, and a Gigabit Ethernet RJ45 port, into a single docking station for maximum productivity.
Display Adaptability
Offering flexible dual video combinations right out-of-the-box, this universal laptop docking station features HDMI, DVI and VGA external monitor outputs. Each video output supports HD video resolutions (2048x1152 max) and HD video playback for an ideal solution to expanding your notebook's video capability.
Available display combinations:
• HDMI + VGA
• HDMI + DVI
Integrated USB Hub
The built-in USB hub features three USB 3.0 ports for connecting extra peripherals such as external hard drives or a wired mouse, as if they are connected directly to your laptop.
Direct Ethernet Connectivity
The integrated RJ45 Ethernet port supports speeds of 10/100/1000 Mbps, giving you an instant connection to a wired network.
StarTech.com laptop docking stations can be used for cost savings and faster deployment with just a single cable. This USB 3.0 Docking Station is backed by a competitive 3-year warranty and free lifetime Technical Support.
This USB 3.0 dock combines three USB 3.0 ports, headphone and microphone audio connectors, and a Gigabit Ethernet RJ45 port, into a single docking station for maximum productivity.
Display Adaptability
Offering flexible dual video combinations right out-of-the-box, this universal laptop docking station features HDMI, DVI and VGA external monitor outputs. Each video output supports HD video resolutions (2048x1152 max) and HD video playback for an ideal solution to expanding your notebook's video capability.
Available display combinations:
• HDMI + VGA
• HDMI + DVI
Integrated USB Hub
The built-in USB hub features three USB 3.0 ports for connecting extra peripherals such as external hard drives or a wired mouse, as if they are connected directly to your laptop.
Direct Ethernet Connectivity
The integrated RJ45 Ethernet port supports speeds of 10/100/1000 Mbps, giving you an instant connection to a wired network.
StarTech.com laptop docking stations can be used for cost savings and faster deployment with just a single cable. This USB 3.0 Docking Station is backed by a competitive 3-year warranty and free lifetime Technical Support.
Key features
- UNIVERSAL DUAL MONITOR DOCKING STATION: USB 3.0 docking station features HDMI, VGA, and DVI outputs for broad display compatibility; Supports up to 1920x1080 (HDMI), 1920x1200 (DVI-D), and 2048x1152 (VGA); This dual monitor dock is TAA compliant
- INCREASED PRODUCTIVITY: This dual monitor docking station combines 3x USB 3.2 Gen 1 (5Gbps) ports, headphone & mic audio jack, and a Gigabit Ethernet RJ45 port into a single IT-grade dock; Connect directly to older VGA and DVI monitors without adapters
Full specification
59 specifications
- Full duplex
- Yes
- Auto MDI/MDI-X
- Yes
- Networking standards
- IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
- Copper ethernet cabling technology
- 1000BASE-T, 100BASE-TX, 10BASE-T
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Ethernet LAN (RJ-45) ports
- 1
- Ethernet LAN
- Yes
- Operating relative humidity (H-H)
- 0 - 90%
- Storage temperature (T-T)
- -10 - 60 °C
- Operating temperature (T-T)
- 0 - 40 °C
- Chipset
- DisplayLink - DL-3900, Genesys Logic - GL3520, Realtek - RTL8211E
- USB data transfer rates
- 12,480,5000 Mbit/s
- Certification
- FCC, CE, TAA, REACH
- Housing material
- Plastic
- Product colour
- Black
- Cable lock slot type
- Kensington
- Cable lock slot
- Yes
- Maximum analog resolution
- 2048 x 1152 pixels
- Maximum digital resolution
- 1920 x 1200 pixels
- Data transfer rate
- 5 Gbit/s
- Card reader integrated
- No
- DC-in jack
- Yes
- Headphone outputs
- 1
- Microphone in
- Yes
- DVI-D ports quantity
- 1
- VGA (D-Sub) ports quantity
- 1
- HDMI ports quantity
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 3
- Host interface
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B
- Connectivity technology
- Wired
- Compatible power plug types
- AU, EU, UK, US
- Power plug type
- Type B
- Power consumption (typical)
- 20 W
- Output voltage
- 5 V
- Output current
- 4 A
- Input current
- 0.9 A
- AC input voltage
- 100-240 V
- Other operating systems supported
- ChromeOS
- Mac operating systems supported
- Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
- Mac compatibility
- Yes
- Windows operating systems supported
- Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
- Compliance certificates
- RoHS
- Weight
- 295 g
- Height
- 44 mm
- Depth
- 304 mm
- Width
- 178 mm
- Master (outer) case height
- 355 mm
- Master (outer) case width
- 445 mm
- Master (outer) case length
- 228 mm
- Products per master (outer) case
- 6 pc(s)
- Harmonized System (HS) code
- 84733020
- AC adapter included
- Yes
- Cables included
- USB
- Manual
- Yes
- Drivers included
- Yes
- Package weight
- 878 g
- Package height
- 69 mm
- Package depth
- 195 mm
- Package width
- 299 mm
