TP-Linkat301185
TP-Link Omada BE3600 Ceiling Mount Wi-Fi 7 Access Point
Wireless Access PointsIn stock
£128.16
£137.15
inc. VAT
1 / 5
TP-Link
Omada AX1800 Wi-Fi 6 Desktop GPON Access Point
Wireless Access PointsAt a glance
Full specification ↓- Maximum data transfer rate
- 1800 Mbit/s
- Ethernet LAN data rates
- 1000,10,100 Mbit/s
- Colour
- White
- Antenna gain level (max)
- 5 dBi
- Antennas quantity
- 2
- Antenna direction type
- Omni-directional
£137.15inc. VAT
£114.29 ex VAT
In stockDispatched from UK distributor stock
1
- UK delivery direct from distributor stock. Delivery details
- 14-day returns under your statutory cancellation rights. Returns policy
- Secure checkout powered by Stripe.
About this product
TP-Link Omada AX1800 Wi-Fi 6 Desktop GPON Access Point, 2.4 GHz, 5 GHz, 1800 Mbit/s, SNMP, SNMPv2, SNMPv3, SSH, WPA-Personal, WPA2-Personal, WPA3-Personal, 1000,10,100 Mbit/s
AX1800 Wi-Fi 6 Desktop/Wall Mounting GPON Access Point
Complete Omada Optical Networking Solution
The Omada Optical Networking Solution delivers enterprise-grade gigabit passive optical networking. It seamlessly integrates essential components such as Omada switches, gateways, OLTs (Optical Line Terminals), and ONUs (Optical Network Units)—perfect for P2MP (point-to-multipoint) environments like hotels and MDUs.
One Fiber, Multiple Services
Connect a fiber optic cable to the EAP610GP-Desktop to connect cameras, PCs, TVs, and an IP-Phone to carry data, voice, wired and wireless internet, HD video, and VoIP services.
Seamless WiFi 6 Mesh Networking
Leverage GPON WiFi 6 technology for a robust and seamless network experience, delivering speeds up to 1.8 Gbps.* Omada Mesh and 802.11k/v roaming ensure a consistently smooth and reliable connection.
Flexible Desktop/Wall Installation
Choose a suitable installation method according to your needs.
Complete Omada Optical Networking Solution
The Omada Optical Networking Solution delivers enterprise-grade gigabit passive optical networking. It seamlessly integrates essential components such as Omada switches, gateways, OLTs (Optical Line Terminals), and ONUs (Optical Network Units)—perfect for P2MP (point-to-multipoint) environments like hotels and MDUs.
One Fiber, Multiple Services
Connect a fiber optic cable to the EAP610GP-Desktop to connect cameras, PCs, TVs, and an IP-Phone to carry data, voice, wired and wireless internet, HD video, and VoIP services.
Seamless WiFi 6 Mesh Networking
Leverage GPON WiFi 6 technology for a robust and seamless network experience, delivering speeds up to 1.8 Gbps.* Omada Mesh and 802.11k/v roaming ensure a consistently smooth and reliable connection.
Flexible Desktop/Wall Installation
Choose a suitable installation method according to your needs.
Key features
- Seamless 1.8 Gbps WiFi 6 Speeds: 1201 Mbps on 5 GHz & 574 Mbps on 2.4 GHz†
- 1× GPON Port for High-Speed and Ultra-Range Access
- Ultra-Broadband WiFi 6: MU-MIMO, Seamless Roaming§
- One Fiber for Multiple Services: Wired, Wireless, Voice, VoIP, Data, and HD Video Services
- VoIP Calls: Support multiple VolP accounts and various call features, exceeding traditional landlines
Full specification
56 specifications
- Antenna gain level (max)
- 5 dBi
- Antennas quantity
- 2
- Antenna direction type
- Omni-directional
- Antenna type
- Internal
- Certification
- CE, FCC, RoHS, IC
- Compliance certificates
- CE, Federal Communications Commission (FCC), RoHS
- LED indicators
- Power
- Reset button
- Yes
- Product colour
- White
- Placement
- Desk, Wall
- Transmitting power (FCC)
- 25 dBm
- Transmitting power (CE)
- 20 dBm
- BeamForming
- Yes
- Quality of Service (QoS) support
- Yes
- Airtime Fairness (ATF)
- Yes
- Band steering
- Yes
- Wireless isolation
- Yes
- Rate limiting
- Yes
- VLAN support
- Yes
- Wi-Fi roaming
- Yes
- Spread spectrum method
- OFDMA
- MIMO type
- Multi User MIMO
- MIMO
- Yes
- Channel bandwidth
- 80 MHz
- Number of users
- 120 user(s)
- Networking standards
- IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
- Frequency band
- 2.4 - 5 GHz
- Ethernet LAN data rates
- 1000,10,100 Mbit/s
- Maximum data transfer rate (5 GHz)
- 1201 Mbit/s
- Maximum data transfer rate (2.4 GHz)
- 574 Mbit/s
- Maximum data transfer rate
- 1800 Mbit/s
- 5 GHz
- Yes
- 6 GHz
- No
- 2.4 GHz
- Yes
- Syslog
- Yes
- Web-based management
- Yes
- Storage relative humidity (H-H)
- 5 - 90%
- Storage temperature (T-T)
- -40 - 70 °C
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 90%
- Ethernet LAN (RJ-45) ports
- 4
- Power consumption (typical)
- 17.3 W
- DC voltage range
- 53.5 V
- Power over Ethernet (PoE)
- Yes
- Remote Authentication Dial-In User Service (RADIUS)
- Yes
- Number of SSID supported
- 16
- Service Set Identifier (SSID) features
- Multiple SSIDs, SSID broadcast on/off
- MAC address filtering
- Yes
- Security algorithms
- SNMP, SNMPv2, SNMPv3, SSH, WPA-Personal, WPA2-Personal, WPA3-Personal
- Weight
- 492 g
- Height
- 33 mm
- Depth
- 140 mm
- Width
- 175 mm
- Quick start guide
- Yes
- Mounting kit
- Yes
- Quantity per pack
- 1 pc(s)
